TechnologyEM6000 surge protection system


EM6000 is a standard lightning and surge protection device. In order to prevent other connected devices from being damaged by voltage that is too high for a momentary appliance to be able to accept as well. and there are several steps of protection before the damage occurs You can be confident that your electrical appliances will be safe.

Electrical SPEC

Input/Output

  • Single Phase 220VAC

Step 1 Protection

  • Fuse L/N

Step 2 Protection

  • Main Circuit Breaker (MCB)

Step 3 Protection

  • Varistor Arrester Type 2
  • Max. continuous operating voltage (Uc) 275 VAC
  • Max. discharge current (8/20) L/N (Imax) 50 kA
  • Nominal discharge current (8/20) (In) 20 kA
  • Lightning impulse current (10/350) (Iimp) 20 kA
  • voltage protection level (Up) < 1.3 kV
  • TOV L/PE 335V / 5sec.
  • TOV N/PE 1200V / 0.2sec.

Step 4 Protection

  • Lightning Arresters Type 1
  • Max. continuous operating voltage (Uc) 255 VAC
  • Impulse discharge current (10/350) L/PE (Iimp) 50 kA
  • voltage protection level (Up) < 2 kV
  • Follow current interrupt rating (lfi) 3 kArms
  • Max. back-up fuse 500 A gL/gG
  • TOV L/PE 335V / 5sec.
  • Response time 25ns.
  • Test Class According to EN61643-11 and IEC61643-11

Step 5 Protection

  • Lightning Arresters Type 1
  • Max. continuous operating voltage (Uc) 255 VAC / 50Hz
  • Impulse discharge current (10/350) N/PE (Iimp) 100kA
  • voltage protection level (Up) < 2 kV
  • Follow current interrupt rating (lfi) 100 Arms
  • TOV L/PE 1200V / 0.2sec.
  • Response time 25ns.

Step 6 Protection

  • Grounding System Resistance-Earthed < 5 ohms.
  • with Aulminium Cable 50sqmm. and Ground Rod 5/8” @ 18m.

Mechanical SPEC

Display

  • Surge Display Counter and Status

Box material

  • Stainless Steel

Protection Class

  • Housing IP65 (cable entry IP54)

Dimension (WxHxD)

  • 400x400x250mm.

Weight

  • 10kg.
