Draw-wire position sensor EM10000

Features

Very robust construction for mechanical engineering and industrial plant application.

The spindle structure of measuring drum, to ensure meas- urement accuracy up to 0.02%FS, max speed up to 4m/s Max measuring range up to 10.4 meters Signal output RS485, Modbus RTU, Relay Easy to install and to use Have a LCD Color 7 inch display Protection class IP54

Technical data

Hardware Feature and Technical Data

Electrical SPEC

  • CPU 32-bit MIPS Processor
  • Detection system Absolute encoder 12-bit
  • Output signal RS485,Modbus-RTU,Relay
  • resolution ≤0.1mm
  • Accuracy 0.02%FS
  • Power supply 5Vdc 5-26Vdc 10-30Vdc

Mechanical SPEC

  • Measuring range Up to 10.4m
  • Drum circumference 348.7mm
  • Cable diameter 1mm highly flexible steel cable
  • Permissible cable speed Max.4m/s
  • Permissible cable acceleration Max.8m/s
  • Driving force 10-21N
  • Life for cable and spring >2×10 cycle
  • Housing material Anodized aluminum
  • Box material Stainless Steel
  • LCD Display LCD Color 7inch
  • Working temperature -25°C~80°C
  • Storage temperature -40°C~80°C
  • Protection class Housing IP54
  • Mass <5KG
  • Dimension (WDH) 400 x 400 x 250mm
  • Weight 10kg.
  • Protection Upper and Lower Limited Switch
  • Calibration Zero Set Switch
